Q58 Series Piled and Released Type Shot Blasting Machine

Q58 Series Piled and Released Type Shot Blasting Machine

It could be continuous running,it also could be batch or intermittent running. It is flexible production and high productivity.

Casting could pass-through shot blasting zone at lower speed or it will carry out multi position rotation in shot blasting area.It has good cleaning effect.

It could be static loading and unloading material and it is easy for operation.

Inquire Now Next Product

Specification:

Parameter	Unit	Q583	Q585	Q5810	Q588
cleaning workpiece size	mm	Ф800 x1500	Ф800 x1200	Ф1300 x2800	Ф550 x2200
station No.	set	2	4	6	4
blasting wheel quantity	kg	4	6	6	4
blasting capacity	kg/min	4 x250	6 x360	6 x330	4 x480
blasting wheel power	kw	4 x15	6 x22	6x22	4 x22
the max capacity weight of hook	kg	300	500	1000	800
Productivity of every hook	h	40	55	50	30
cleaning room size	mm	3062 x1800 x2800	8500 x1800 x3885	8500 x2300 x4800	6800 x2600 x3325
total ventilation volume	m³/h	15000	18000	18000	17200
total power	kw	74.5	186.85	186.85	121.05

Production Application:

It mainly used for removing sand and surface cleaning of less variety ,mass production and multi variety, middle-small batch production casting.It is widely used.
